Precision Series ™ Linear Amplifiers
The Precision Series™ (P-Series) is EV´s top line of linear
power amplifiers. Their extreme reliability, high-level sound,
and durability make them the professional’s choice among
rental companies and musicians. For flown applications in the touring market, rear-rack
mount kits are available to help stabilize the rack frame and
ensure safe transportation.
P 1200
• Compact, 2 RU chassis
• Switchable limiter constant (fast/slow)
• Switchable Lo- and Hi-cut filter
• Input transformer optional (NRS 90176)
• Selectable input sensitivity with 26 dB
constant gain option (internal)
P 2000 / P 3000
• Dual power-supply
• Switchable limiter constant (fast/slow)
• Switchable Lo- and Hi-Cut filter
• Input transformer optional (NRS 90176)
• Selectable input sensitivity with 26 dB
constant gain option (internal)
P1200 P 2000 P 3000
Continous rated power (1k Hz, THD 1 %)
2 ohms
800 watts 1200 watts 1800 watts
4 ohms 550 watts 900 watts 1300 watts
8 ohms 370 watts 560 watts 850 watts
Continous rated power (20 - 20k Hz, THD < 0,1%)
4 ohms
500 watts 800 watts 1200 watts
8 ohms 350 watts 500 watts 750 watts
Max. bridged output
4 ohms
1600 watts 2400 watts 3600 watts
8 ohms 1100 watts 1800 watts 2600 watts
Slew rate > 30 V / µs > 35 V / µs > 40 V / µs
Total Harmonic Distortion < 0.05% < 0.05% < 0.05%
Intermodulation Distortion (SMPTE) < 0.01% < 0.01% < 0.01%
DIM 30 < 0.01% < 0.01% < 0.01%
Damping factor 100 Hz / 1000 Hz > 400 / > 300 > 400 / > 300 > 400 / > 300
Crosstalk (at 1.000 Hz) < -70 dB < -70 dB < -70 dB
Signal-to-noise ratio (dB A-weighted) > 105 dB > 105 dB > 105 dB
Input Impedance (20-20k Hz, balanced) 20k ohms 20k ohms 20k ohms
Input Sensitivity (0 dBu factory setting) 0 dBu / +6 dBu / +26 dB 0 dBu / +6 dBu / +26 dB 0 dBu / +6 dBu / +26 dB
constant gain constant gain constant gain
Input connectors, parallel out XLR in/out XLR in/out XLR in/out
Output connectors Speakon (Pin 1) Speakon (Pin 1) Speakon (Pin 1)
Dimensions mm (H x W x D) 88 x 483 x 390 mm 133 x 483 x 390 mm 133 x 483 x 390 mm
3.5” x 18” x 16.8” 5.2” x 19” x 16.8” 5.2” x 19” x 16.8”
Net weight 17 kg (35.2 lbs.) 27 kg ( 57.3 lbs.) 29 kg (61.7 lbs.)
THD + N versus power output of a P 3000.
