40
Subwoofers
Xi-2181(F) Xsub(F) XLC 118 Plasma P2
Application Installation Concert Sound Concert Sound Concert Sound
Concert Sound Installation Installation Installation
Woofer Type 1 x 18” 2 x 18” 1 x 18” 1 x 18”
Power Handling cont. 600 W 1200 W 600 W 600 W
Sensitivity(1W1m) 94 dB /100 dB* 100 dB /106 dB* 96 dB /102 dB* built in Amplifier 800W
Max. SPL (peak) 128 dB /134 dB* 137 dB /143 dB* 130 dB /136 dB* 126 dB /132 dB*
Internal X-Over no no no Lowpass 100 Hz
Flying L-track in F-version X-Line rigging, F-vers. XLC rigging
Dimension H/W/D 914 x 586 x 759 mm 494.3 x 1245 x 740 mm 546 x 991 x 572 mm 910 x 476 x 600 mm
36” x 23.1” x 29.9” 19.5” x 49” 29.1” 21.5” x 39” x 22.5” 35.8” x 18.7 x 23.6”
Weight 68 kg (149.9 lbs.) 92 kg (202.8 lbs.) 54.5 kg (120.2 lbs.) 63.6 kg (140.2 lbs.)
* 1/2-space SPL
QRx118S MTL1X QRx218S XDS
Application Pro Music Pro Music Pro Music Concert Sound
Concert Sound Concert Sound Concert Sound
Woofer Type 1 x 18” 2 x 18” 2 x 18” 2 x 18”
Power Handling cont. 600 W 1200 W 1200 W 1200 W
Sensitivity(1W1m) 98 dB /104 dB* 101 dB /107 dB* 99 dB /105 dB* 100 dB /106 dB*
Max. SPL (peak) 132 dB /138 dB* 137 dB / 141 dB* 134 dB /140 dB* 137 dB /143 dB*
Internal X-Over no no no no
Flying no no optional no
Dimensions H/W/D 900 x 450 x 600 mm 1160 x 572 x 758 mm 990 x 560 x 600 mm 914 x 1166 x 759 mm
35.4” x 17.7” x 23.6” 45.8” x 22.5” x 29.9” 39” x 22” x 23.6” 36” x 45.9” x 29.9”
Weight 47.5 kg (104.7lbs.) 48.5 kg (106.9 lbs.) 56.5 kg (124.6 lbs.) 121 kg (266.8 lbs.)
