2-Way Stereo (Mono Sub) Pop Band or Disco in smaller room
2-Way Stereo Standard PA for Concert & Disco
Cabinets 2 x QRx212/75, 3 x QRx118S
Amplifiers 1 x P1201, 1 x P1202
Controllers 2 x M-212 & 1 x M-118 Module
Cabling 3 x NL4 long, 2 x NL4 short
Accessories 2 x QRx Rigging Kit, 3 x QRx Wheel Kit
Horizontal Coverage 2 x 75°
Typical Distance 15 m to 20 m
Total Amp Power 2 x 600W + 1.500W = 2.700W
Options
Comments System could be doubled for larger rooms
Cabinets 4 x QRx115/75, 4 x QRx218S
Amplifiers 4 x P1202
Controllers 2 x M-115 & 2 x M-218 Module
Cabling 8 x NL4 long
Accessories 4 x QRx Rigging Kit, 4 x QRx Wheel Kit
Horizontal Coverage 2 x 100° to 150°, or 4 x 75°
Typical Distance 15 m to 20 m
Total Amp Power 2 x 1,900W = 3,800W
Options add 2 M-115 & M-218 Modules to split
system into two separate systems
Comments
