Electro-Voice Microphone - Manual (Page 22)

22
Sb 121
• Subwoofer
• Direct
radiating
vented design
• Trapezoidal (25° per side)
• Recommended low-pass
between 100 Hz - 200 Hz
(12dB/Oct.)
• 4 x M8x1.25 attachment
points
Sx 80/PI/PIX
• 2-Way Full-range
• Vented LF enclosure
• 1” voicecoil (titanium
diaphragm)
• PRO™ Driver protection
• HF-horn features Varipath™
• Trapezoidal
• Compact
dimensions
• 7 x M6 and 4 x M5 inserts
• For overview of variants, see
chart at right
• PIX (70V/100V)
Sx 100 +
• 2-Way Full-range
• Vented LF enclosure
• 1.25” voice coil
(titanium diaphragm)
• PRO™ Driver protection circuit
• HF-horn features Varipath™
• Trapezoidal (25° per side)
• Physical characteristics of
Sx 300 with slightly lower
sensitivity
• 4 x M8x1.25 attachment inserts
Sx 300/PI/PIX
• 2-Way Full-range
• High Sensitivity
• Ultra-linear frequency response
• Vented LF enclosure
• 1.25” voice coil
(titanium diaphragm)
• PRO™ Driver protection circuit
• HF-horn features Varipath™
• Trapezoidal (25° per side)
• 4 x M8x1.25 attachment inserts
• Overview of variants see
right spread sheet
• Sx300 PI outdoor version
• Sx300 PIX for 70V/100V
• 2-Way Full-range
• Extended bass response
• 15” DL-Woofer
• 1.25” titanium diaphragm
• 80 x 55 degree horn pattern
• 18mm plywood enclosure
• Rugged FUTURA TM finish
• Five sided, multi-angle cabinet
• Built-in stand mount
• Suspendable using optional SK-1 kit
Sx 250
PI version
For the last twenty years, EV’s Sx Series loudspeakers have
been the industry standard for lightweight, high-performance
loudspeakers, a standard against which all others are meas-
ured. Their versatility is reinforced by their rich portfolio of
accessories, from wall-mount and array brackets to monitor feet and transport bags. The Sx series has powered every-
thing from local wedding bands to the clogs of “Riverdance”
to football games at Notre Dame Stadium, and the new
Sx600 dominates the stadiums at the 2004 Olympic
Summer Games in Athens, Greece.
Sx-Series TM
