Electro-Voice Microphone - Manual (Page 39)

39
Subwoofers
EVID 12.1 EVID C10.1 FRi + 181S FRX+181
Application Installation Ceiling Installation Installation Installation
Woofer Type 1 x 12” slot loaded 1 x 10” 1 x 18” 1 x 18”
Power Handling cont. 2 x 175 W 150 W 400 W 400 W
Sensitivity(1W1m) 100 dB** 94 dB* 97 dB/103 dB* 96 dB/102 dB*
Max. SPL (peak) 125 dB ** 122 dB * 129 dB/135 dB* 128 dB /134 dB*
Internal X-Over stereo w/ hi-pass out lowpass no no
Flying no no eyebolts L-track
Dimensions H/W/D (mm) 412 x 584 x 305 mm 320 mm diameter 711 x 597 x 762 mm 787 x 719 x 660 mm
16.22” x 23” x 12” 12.6” diameter 27” x 23.5” x 30” 31” x 28.3” x 26”
Weight 18.1 kg (39.9 lbs.) 7 kg (15.4 lbs.) 45.5 kg (100.3 lbs.) 45.5 kg (100.3 lbs.)
Eliminator i Sub Eliminator KW Sb 121 SbA 760
Application Pro Music Pro Music Pro Music, Pro Music,
Installation Installation
Woofer Type 1 x 18” 2 x 18” 1 x 12” 1 x 15”
Power Handling cont. 400 W 1000 W AES 300 W 760 W amplifier
Sensitivity(1W1m) 98 dB/104 dB* 101 dB/107 dB* 95 dB/101 dB*
Max. SPL (peak) 130 dB/136 dB* 137 dB/143 dB* 126 dB/132 dB* 128 dB/134 dB*
Internal X-Over lowpass no no built-in active X-Over
Flying no no optional SX Hardware no
Dimension H/W/D (mm) 856 x 429 x 609 1140 x 569 x 597 586 x 429 x 312 603 x 428 x 665
33.7” x 16.9” x 24” 44.9” x 22.4” x 23.5” 23.1” x 16.9” x 12.3” 23.7” x 16.9” x 26.2”
Weight 33.6 kg (74 lbs.) 65.8 kg (145 lbs.) 14.6 kg (32.2 lbs.) 43 kg (94.8 lbs.)
* 1/2-space SPL, ** 1/4-space SPL
