P 1201

• Single channel
• Modular controller amp concept
• Input transformer optional (NRS 90208)
• Without controller cards, useable as linear

amp with fixed +6 dBu input sensitivity

P 1202

• Dual channel
• Modular controller amp concept
• Input transformer optional (NRS 90208)
• Without controller cards, useable as linear

amp with fixed +6 dBu input sensitivity

Modular P-Series amplifiers guarantee the same quality and
performance standards as linear P-Series amplifiers but are
designed for dedicated EV systems such as the QRx Series.
They combine highest-quality signal control, maximum
speaker-operation safety, and the extreme reliability of linear
P-Series amps within a modular controlled amplifier concept.

This all adds up to maximum flexibilty and an economic
alternative to digitally controlled amp racks. Rear-rackmount
kits are available in a 15.5-inch version (NRS 90235) or 18-
inch version (NRS 90223) to help stabilize the rack frame
and ensure safe transportation.

Precision Series

™

Modular Amplifiers

P 1201

P 1202

Continous rated power (1k Hz, THD 1 %)
2 ohms

1600 watts

850 watts

4 ohms

1200 watts

600 watts

8 ohms

750 watts

380 watts

Continous rated power (20 - 20k Hz, THD < 0,2%)
4 ohms

1000 watts

500 watts

8 ohms

500 watts

300 watts

Max. bridged output
4 ohms

N/A

1700 watts

8 ohms

(single channel!)

1200 watts

Slew rate

> 40 V / µs

> 30 V / µs

Total Harmonic Distortion

< 00.5%

< 0.05%

Intermodulation Distortion (SMPTE)

< 0.08.%

< 0.08%

DIM 30

< 0.03%

Damping factor 100 Hz / 1000 Hz

> 300 / > 200

Crosstalk (at 1 kHz)

---

Signal-to-noise ratio (dB A-weighted)

> 106 dB

Input Impedance (20-20k Hz, balanced)

20 kohms

Input Sensitivity (without module)

6 dBu fix

Input connectors, parallel out

XLR in/out

Output connectors

Speakon (Pin 1)

Dimensions mm (H x W x D)

133 x 483 x 390 mm

5.2” x 19” x 16.8”

Net weight (without modules)

17 kg (37.5 lbs.)

P1202/P1201
Control Modules

These controller cards provide customized sys-
tem equalization, crossover design, and EV´s
unique voice-coil protection circuit (VCP) for use
with EV loudspeakers (modules for QRx speak-
ers are currently available). Cards for full-range
systems feature a switchable 3,000 Hz (Q = 1, -
3 dB) DIP-EQ and a flush-mounted operation
mode switch. Each module also includes a “1-
in-2” switch on the PCB board, allowing it to
drive both channels of a P1202 independently
while using only one controller card. Note that
when a module is used, the amplifier’s input
sensitivity changes to 0 dBu.

M-112

M-115

M-212

M-LMH

Dedicated for

Rx-112/75

Rx-115/75

Rx-212/75

12/15-2

Operation function

Full-range / Mid-High Full-range / Mid-High

Full-range / Mid-High

Frequency Response (-6 dB)

27 - 50k Hz

25 - 50k Hz

27 - 50k Hz

Full-range mode
Frequency Response (-6 dB)

75 - 50k Hz

Mid-High mode
Adjustable gain-range

- 85 dB to + 6 dB

S/N Ratio

< 105 dB

THD + N

< 0.05%

M-118S

M-215S

M-218S

M-SUB

Dedicated for

Rx-118S

Rx-215S

Rx-218S

18”

Operation function

Subwoofer

Frequency Response (-6 dB)

25 - 90k Hz

Full-range mode
Frequency Response (-6 dB)

---

Mid-High mode
Adjustable gain-range

- 85 dB to + 6 dB

S/N Ratio

< 108 dB

THD + N

< 0.05%
