Xi-Series ™
Xi-Series™ brings premium touring-quality sound into
installation. Inspired by the features of EV´s acclaimed
X-Array™ touring systems, the Xi-Series™ incorporates a
potent combination of very-high-output and ultra-linear
short-, medium- and long-throw systems, in two-way,
three-way and four-way configurations. Xi-Series™ incorpo-
rates the acoustical advantage of EV´s unique Ring-Mode
Decoupling (RMD™) and features HP horns to secure excel-
lent directivity control and even coverage. A unique feature of the three-way systems is Vertical Beam
Shaping (VBS). The three-way systems may be in 2-element
or 3-element configuration to extend the vertical coverage-
angle control to as low as 125 Hz, well below that permitted
by the mid-bass horn alone (which typically has a band fre-
quency of 800 Hz): Unprecedented performance in a one-
box system!
To achieve sound performance without compromises, Xi-
Series™ is designed for multi-way active operation, except
Xi-1082 which contains a passive crossover network.
Xi-1082
• 2-Way Full-range
• Vented LF enclosure
• 1.3” voice coil (titanium diaphragm)
• Typical under-balcony slant also perfect
for front-stage and near-field use
• 2 x 3/8”-16 mounting bracket inserts
Xi-1122A/85F
• 2-Way Full-range
• Vented LF enclosure
• 3” voice coil (titanium diaphragm)
• Integrated 35 mm stand mount
• Trapezoidal (15° per side)
Xi-1152A/64F
(60° x 40°)
Xi-1152A/94F
(90° x 40°)
• 2-Way Full-range
• Solid bass down to 50 Hz (-3 dB)
• Vented LF enclosure
• 3” voice coil (titanium diaphragm)
• Integrated 35 mm stand mount
• Trapezoidal (15° per side)
