• 3-way output near-field
• MB/HF section horn-loaded

and rotatable

• Height same as Xf, Xb
• Excellent directivity control
• Trapezoidal (9° per side)

Xcn

• 2-way output near-field
• Height same as Xcb
• MB/HF section identical to

Xn and rotatable

• Excellent directivity control
• Trapezoidal (9° per side)

Xcb

• High-output LF cabinet
• Vented design
• Height same as Xcn
• Equivalent to half of an Xb
• Accurate transient detail
• Trapezoidal (9° per side)

Xds

• Extraordinary output

low-end sub

• Manifolded, vented design
• Accurate transient detail
• Trapezoidal (18° per side)
• Designed for ground

stacking

Xw 12 / Xw 15

• 2-way high-output

Floor monitor

• Vented LF enclosure
• 3” voice coil (titanium

diaphragm) for low distortion

• Two symmetrical 55° angles

• 2-way output far-field
• MB/HF section horn-loaded
• Height same as Xn, Xb
• Excellent directivity control
• Trapezoidal (9° per side)

• High-output LF cabinet
• Manifolded, vented design
• Height same as Xn, Xf
• Accurate transient detail
• Trapezoidal (9° per side)

Xf, Xn and Xb look
identical

Xcn and Xcb look
identical

Sketch of a Xf

Xcn

Frequency Range (-3 dB)

140 Hz - 20 KHz

48 Hz - 20 KHz

125 Hz - 20 KHz

37 Hz - 200 Hz

Recommended High-Pass Frequency

Systemcontroller

Axial Sensitivity SPL 1W/1m

112/116 dB

95/110/112 dB

110/112 dB

98.5 dB

Max. SPL / 1m (calc.); full space

146/144 dB

129/141/137 dB

141/137 dB

135 dB

Long-Term Power Handling

600/150 W

600/300/75 W

300/75 W

1.200 W

Short-Term Power Handling (Peak)

2.400/600 W

2.400/1.200/300 W

1.200/300 W

4.800 W

Coverage (nominal -6 dB) H° x V°

40° x 20° (CD Horn)

60° x 40° (CD Horn)

240° x 300° (63-200 Hz)

Directivity Index

17.2 dB (+2.0/-2.7 dB)

13.7 dB (+1.4/-1.4 dB)

13.4 dB (+2.0/-1.8 dB)

3.4 dB (+1.4/-0.9 dB)

800 Hz - 16 KHz

63 - 200 Hz

LF woofer (transducer)

18" (EVX-180B)

2 x 18" (EVX-180B)

MB woofer (transducer)

2 x 12" (ND12A)

12" (ND12A)

---

HF throat diameter (transducer)

2 x 1.4" (ND6-16)

1.4" (ND6-16)

---

Crossover Frequencies

Systemcontroller

Nominal Impedance

Ω

/16

Ω

/16

Ω

/16

Ω

2 x 8

Ω

Minimum Impedance

4.9

Ω

/7.0

Ω

6.5

Ω

/9.4

Ω

/14.0

Ω

9.9

Ω

/12.9

Ω

2 x 6.4

Ω

Input Connections

2 eight-pin Speakon

Dimensions (H x W at front x D)

1.067 x 584 x 759 mm

596 x 584 x 759 mm

1.067 x 584 x 759 mm

42” x 22.99” x 29.88”

23.47” x 22.99” x 29.88”

42” x 22.99” x 29.88”

Net Weight

87.1 kg (192 lbs.)

60.8 kg (134 lbs.)

83.5 kg (184 lbs.)

Xcb

Xds

Xw12

Xw15

Frequency Range (-3 dB)

37 Hz - 200 Hz

32 Hz - 200 Hz

60 Hz - 16 KHz

50 Hz - 16 KHz

Recommended High-Pass Frequency

Systemcontroller

Axial Sensitivity SPL 1W/1m

95 dB

100 dB

99/110 dB

Max. SPL / 1m (calc.); full space

129 dB

137 dB

130/135 dB

133/135 dB

Long-Term Power Handling

600 W

1.200 W

300/75 W

600/75 W

Short-Term Power Handling (Peak)

2.400 W

4.800 W

1.200/300 W

2.400/300 W

Coverage (nominal -6 dB) H° x V°

300° x 270° (63-200 Hz)

180° x 200° (63-200 Hz)

55° x 80° (CD Horn)

Directivity Index

2.7 dB (+1.0/-0.6 dB)

4.8 dB (+2.1/-1.7 dB)

11.6 dB (+2.3/-2.1dB)

11.6 dB (+3.0/-3.6dB)

63 - 200 Hz

1,200 Hz - 16 KHz

LF woofer (transducer)

18" (EVX-180B)

2 x 18" (EVX-180B)

12" (DL-type)

15" (EVX-155)

MB woofer (transducer)

---

HF throat diameter (transducer)

---

1.4" (DH7)

Crossover Frequencies

System controller

Nominal Impedance

Ω

2 x 8

Ω

/16

Ω

/16

Ω

Minimum Impedance

5.6

Ω

2 x 6.1

Ω

8.2

Ω

/10.5

Ω

7.2

Ω

/14.3

Ω

Input Connections

2 eight-pin Speakon

2 four-pin Speakon

Dimensions (H x W at front x D)

596 x 584 x 759 mm

914 x 1.166 x 759 mm

358 x 584 x 409 mm

389 x 644 x 461 mm

23.47” x 22.99” x 29.88”

35.98” x 45.91” x 29.88”

14.09” x 22.99” x 16.10”

15.32” x 25.35” x 18.15”

(in floor position)

Net Weight

55.8 kg (123 lbs.)

121.0 kg (266.8 lbs.)

28.2 kg (62.2 lbs.)

31.8 kg (70.1 lbs.)
