6. Menu Display and Settings 90
Audio Menu
This section describes the function and settings of each menu item.
Factory default settings are shown in bold (for example,
18dB ).
Refer to “Block Diagrams” (page 124).
Audio >Audio Input
Sets audio input settings.
Item Sub-item setting Description
CH1 Input
Select INPUT1 / Internal MIC / Shoe CH1 Switches the input source for recording
on channel 1.
CH2 Input
Select INPUT1 / INPUT2 / Internal MIC / Shoe CH2 Switches the input source for recording
on channel 2.
CH3 Input
Select Off / INPUT1 / Internal MIC / Shoe CH1 Switches the input source for recording
on channel 3.
CH4 Input
Select Off / INPUT1 / INPUT2 / Internal MIC /
Shoe CH2
Switches the input source for recording
on channel 4.
INPUT1 MIC
Reference –80dB / –70dB / –60dB / –50dB / –40dB /
–30dB
Sets the reference recording level for XLR
microphone input from INPUT1.
INPUT2 MIC
Reference –80dB / –70dB / –60dB / –50dB / –40dB /
–30dB
Sets the reference recording level for XLR
microphone input from INPUT2.
Line Input
Reference +4dB / 0dB / –3dB / EBUL Selects the reference input level when
the INPUT1/INPUT2 switch is set to LINE.
Reference
Level –20dB / –18dB / –16dB / –12dB / EBUL Selects the recording level of the 1 kHz
reference tone signal.
CH1 Wind
Filter On / Off Enables/disables the wind reduction
filter for channel 1 recording.
CH2 Wind
Filter On / Off Enables/disables the wind reduction
filter for channel 2 recording.
CH3 Wind
Filter On / Off Enables/disables the wind reduction
filter for channel 3 recording.
CH4 Wind
Filter On / Off Enables/disables the wind reduction
filter for channel 4 recording.
CH3 Level
Control Auto / Manual Selects automatic audio input level
adjustment or manual adjustment for
recording channel 3.
[Note]
If both CH3 Input Select and CH4 Input Select
are set to Internal MIC, CH4 is switched to
automatic/manual in conjunction with this
setting.
Audio >Audio Input
Sets audio input settings.
Item Sub-item setting Description
CH4 Level
Control Auto / Manual Selects automatic audio input level
adjustment or manual adjustment for
recording channel 4.
[Note]
If both CH3 Input Select and CH4 Input Select
are set to Internal MIC, CH4 is switched to
automatic/manual in conjunction with the CH3
Level Control setting.
CH3 Input
Level 0 to 99 ( 49 ) Sets the input level for recording channel
3.
CH4 Input
Level 0 to 99 ( 49 ) Sets the input level for recording channel
4.
Audio Input
Level 0 to 99 Sets the audio input level.
Can be used as the master volume,
according to the settings of CH1 Level to
CH4 Level.
Limiter Mode Off / –6dB / –9dB / –12dB / –15dB / –17dB Selects the limiter characteristic for large
input signals when adjusting the audio
input level manually.
CH1&2 AGC
Mode Mono / Stereo Sets the auto level adjustment mode for
recording channel 1 and channel 2. When
set to Stereo, the AGC is linked between
channels.
CH3&4 AGC
Mode Mono / Stereo Sets the auto level adjustment mode for
recording channel 3 and channel 4. When
set to Stereo, the AGC is linked between
channels.
AGC Spec –6dB / –9dB / –12dB / –15dB / –17dB Selects the AGC characteristic.
1kHz Tone on
Color Bars On / Off Turns the 1 kHz reference tone signal on/
off when displaying color bars.
[Note]
When set to On, the 1 kHz reference tone signal
is set for recording on channel 3 and channel 4,
even if CH3 Input Select and CH4 Input Select
are set to Off.
