1. Overview: Screen Display

15

Assignable Button Status screen

Displays the functions assigned to each of the
assignable buttons.

Display item

Description

1

Function assigned to the
ASSIGN 1 button

2

Function assigned to the
ASSIGN 2 button

3

Function assigned to the
ASSIGN 3 button

4

Function assigned to the
ASSIGN 4 button

5

Function assigned to the
ASSIGN 5 button

6

Function assigned to the
ASSIGN 6 button

7

Function assigned to the
ASSIGN 7 button

8

Function assigned to the
ASSIGN 8 button

9

Function assigned to the
ASSIGN 9 button

Focus Hold
Button

Function assigned to the
Focus Hold button of the
lens

Multi Function
Dial

Function assigned to the
multi-function dial

Grip Dial

Function assigned to the
grip assignable dial

Handle Dial

Function assigned to the
handle assignable dial

Battery Status screen

Displays information about the battery and DC
IN source.

Display item

Description

Detected Battery Type of battery
Remaining

Remaining capacity (%)

Charge Count

Number of recharges

Capacity

Remaining capacity (Ah)

Voltage

Battery voltage (V)

Manufacture
Date

Date of battery manufacture

Video Light
Remaining

Displays the remaining
capacity of the video light
battery.

Power Source

Power supply source

Supplied Voltage Supplied power source

voltage

Media Status screen

Displays the remaining capacity and remaining
recording time of recording media.

Display item

Description

Media A
information

Displays the media icon
when recording media is
inserted in slot A.

Media A
remaining
capacity meter

Displays the remaining
capacity of recording media
inserted in slot A expressed
as a percentage on a bar
graph.

Media A
remaining
recording time

Displays an estimate of the
remaining recording time of
the recording media
inserted in slot A in units of
minutes under the current
recording conditions.

Media B
information

Displays the media icon
when recording media is
inserted in slot B.

Media B
remaining
capacity meter

Displays the remaining
capacity of recording media
inserted in slot B expressed
as a percentage on a bar
graph.

Media B
remaining
recording time

Displays an estimate of the
remaining recording time of
the recording media
inserted in slot B in units of
minutes under the current
recording conditions.

Network Status screen

Displays the network connection status.

Display item

Description

Wireless LAN

Wireless network settings
and connection status

Wired LAN

Wired LAN network settings
and connection status

Modem

Wireless network settings
and connection status of
USB tethering

File Transfer Status screen

Displays file transfer information.

Display item

Description

Auto Upload
(Proxy)

Auto Upload (Proxy) function
On/Off status

Job Status
(Remain / Total)

Remaining number of jobs
and total number of jobs

Total Transfer
Progress

Transfer progress of all jobs

Default Upload
Server

Name of Auto Upload
(Proxy) destination server

Current File
Transfer Progress

Transfer progress of current
file transfer

Current
Transferring File
Name

Name of file currently being
transferred

Server Address

Address of file transfer
destination server

Destination
Directory

Destination directory of file
transfer destination server
