3. Shooting: Setting the Audio to Record 47
Adding Audio Input Connectors
You can connect up to four channels of XLR
audio devices to the camcorder at the same
time by using an XLR-K2M XLR adaptor
(not supplied) or XLR-K3M XLR adaptor (not
supplied).
Attach the XLR adaptor to the multi-interface
shoe, and set CH3 >Source to Shoe CH1 and
CH4 >Source to Shoe CH2 on the Audio Status
screen (page 14). Or, set Audio Input >CH3
Input Select to Shoe CH1 and CH4 Input Select
to Shoe CH2 in the Audio menu of the full
menu.
Camcorder functions that overlap will be
disabled for channels on which the XLR
adaptor is selected as the input. Use the
switches and dials on the XLR adaptor to
perform adjustments.
[Notes]
ˎ ˎ The camcorder supports the digital 2ch audio
interface of the XLR-K3M.
ˎ ˎ If Audio Input >CH3 Level and CH4 Level in the Audio
menu are set to Audio Input Level, then Audio Input
Level on the camcorder is multiplied by the level
adjusted on the XLR adaptor.
Audio Input Level is also enabled when the XLR
adaptor switch is set to AUTO.
When “Through” is specified, audio will be recorded at
the level adjusted with the XLR adaptor (page 125).
