Tables and overviews
18.3 Technical information
18
614
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 2/2015
User functions
Display modes
x
Plan view / projection in 3 planes / 3-D view / 3-D line graphics
x Magnification of details
Programming graphics
■ In the Programming mode, the contour of the NC blocks is drawn on
screen while they are being entered (2-D pencil-trace graphics), even
while another program is running
Program-run graphics
Display modes
x
Graphic simulation of real-time machining in plan view / projection in 3
planes / 3-D view
Machining time
■ Calculation of machining time in the Test Run operating mode
■ Display of the current machining time in the Program Run, Single
Block and Program Run, Full Sequence operating modes
Datum management
■ For saving any reference points
Contour, returning to
■ Mid-program startup in any block in the program, returning the tool to
the calculated nominal position to continue machining
■ Program interruption, contour departure and return
Datum tables
■ Multiple datum tables, for storing workpiece-related datums
x
Calibrating the touch probe
x
Compensation of workpiece misalignment, manual or automatic
x Datum setting, manual or automatic
Touch probe cycles
x
Automatic workpiece measurement
x
Tools can be measured automatically
