14.7 Using 3-D touch probes (option 17)
Overview
The following touch probe cycles are available in the Manual
Operation mode:
HEIDENHAIN only gives warranty for the function of
the probing cycles if HEIDENHAIN touch probes are
used.
The TNC must be specially prepared by the machine
tool builder for the use of a 3-D touch probe. Refer to
your machine manual.
Soft key Function Page
Calibrating the 3-D touch probe 502
Measuring a 3-D basic rotation by
probing a plane
513
Measuring a basic rotation using
a line
510
Setting a datum in any axis 515
Setting a corner as datum 516
Setting a circle center as datum 517
Setting the centerline as datum 519
Touch probe system data
management
See User’s
Manual for
Cycles
For more information about the touch probe table,
refer to the User’s Manual for Cycle Programming.
