Programming: Data transfer from CAD files
7.3 DXF converter (option 42)
7
258
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 2/2015
Opening a DXF file
Select the Programming mode of operation
Select File functions.
In order to see the soft-key menu for selecting the
file type to be displayed, press the
SELECT TYPE
soft key
In order to show all CAD files, press the
SHOW
CAD soft key
Select the directory in which the CAD file is saved
Select the desired CAD file
Load it with the
ENT key. The TNC starts the DXF
converter and shows the contents of the file on
the screen. The TNC shows the layers in the list
view window, and the drawing in the graphics
window
