First steps with the TNC 620
1.3 Programming the first part
1
56
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 2/2015
Select the approach function APPR CT: Enter the
coordinates of the contour starting point 1 in X and
Y, e.g. 5/5, confirm with the ENT key
Center angle? Enter the approach angle, e.g. 90°,
confirm with the
ENT key
Circle radius? Enter the circular radius, e.g. 8 mm,
confirm with the
ENT key
Confirm the Radius comp.: RL/RR/no comp? with
the RL soft key: Activate the radius compensation
to the left of the programmed contour
Feed rate F=? Enter the machining feed rate, e.g.
700 mm/min, save your entry with the
END key
Machine the contour and move to contour
point
2
: You only need to enter the information
that changes. In other words, enter only the Y
coordinate 95 and save your entry with the
END
key
Move to contour point
3 : Enter the X coordinate 95
and save your entry with the END key
Define the chamfer at contour point
3
: Enter the
chamfer width 10 mm and save with the END key
Move to contour point 4 : Enter the Y coordinate 5
and save your entry with the END key
Define the chamfer at contour point 4 : Enter the
chamfer width 20 mm and save with the END key
Move to contour point
1
: Enter the X coordinate 5
and save your entry with the END key
Depart the contour
Select the departure function DEP CT
Center angle? Enter the departure angle, e.g. 90°,
confirm with the
ENT key
Circle radius? Enter the departure radius, e.g. 8
mm, confirm with the
ENT key
Feed rate F=? Enter the positioning feed rate, e.g.
3000 mm/min, confirm with the
ENT key
Miscellaneous function M? Switch on the coolant,
e.g.
M9, confirm with the END key: The TNC saves
the entered positioning block
Retracting tool: Press the orange axis key
Z and
enter the value for the position to be approached,
e.g. 250. Press the
ENT key
Confirm Radius comp.: RL/RR/no comp? by
pressing the ENT key: Do not activate the radius
compensation
Confirm
Feed rate F=? with the ENT key: Move at
rapid traverse ( FMAX)
MISCELLANEOUS FUNCTION M? ENTER M2 to end
the program and confirm with the
END key: The
TNC saves the entered positioning block
