Working with the parallel axes U, V and W

11.3

TNC 620 | User's Manual

HEIDENHAIN Conversational Programming | 2/2015

393

Deactivating FUNCTION PARAXMODE

After the TNC is started up, the standard configuration

is always effective.
The parallel-axis function

PARAXMODE OFF is

automatically reset by the TNC via the following

functions:

Selection of a program
End of program
M2 or M30
PARAXMODE OFF

You must deactivate the parallel-axis functions before

switching the machine kinematics.

Use the

PARAXMODE OFF function to switch off the parallel-axis

function. The TNC then uses the principal axes defined by the

machine manufacturer. Proceed as follows for the definition:

Show the soft-key row with special functions

Select the menu for defining various plain-language

functions

Select

FUNCTION PARAX

Select

FUNCTION PARAXMODE

Select

FUNCTION PARAXMODE OFF

NC block

13 FUNCTION PARAXMODE OFF
