Programming: Q parameters
9.8 Additional functions
9
322
TNC 620 | User's Manual
HEIDENHAIN Conversational Programming | 2/2015
Group name, ID no. Number Index Meaning
TS triggering touch probe, 350 50 1 Touch probe type
2 Line in the touch-probe table
51 - Effective length
52 1 Effective ball radius
2 Rounding radius
53 1 Center offset (reference axis)
2 Center offset (minor axis)
54 - Spindle-orientation angle in degrees (center
offset)
55 1 Rapid traverse
2 Measuring feed rate
56 1 Maximum measuring range
2 Safety clearance
57 1 Spindle orientation possible: 0=No, 1=Yes
2 Spindle-orientation angle
TT tool touch probe 70 1 Touch probe type
2 Line in the touch-probe table
71 1 Center point in reference axis (REF system)
2 Center point in minor axis (REF system)
3 Center point in tool axis (REF system)
72 - Probe contact radius
75 1 Rapid traverse
2 Measuring feed rate for stationary spindle
3 Measuring feed rate for rotating spindle
76 1 Maximum measuring range
2 Safety clearance for linear measurement
3 Safety clearance for radial measurement
77 - Spindle speed
78 - Probing direction
