Welltech SIPPBX 6200 V.3.1.1 - Manual (Page 85)

Welltech Technology Co., Ltd.
SIPPBX 6200S, 6200GS, 6200N Release 3.1.1
User Guide
- 85 -
register to SIPPBX 6200x, we may define 629 as short code. To call
extension in between, only dial short code 629 instead of dialing complete
digits.
• Display Name: Change SIP signal field display name to an readable name
which may display at IP phone. This name can be an word or number but it
can’t be regarded as call back number.
• Use Forwarder Display Name: Add display name as subscriber ID in SIP
from header in SIP protocol when call forward caller mode is " Forwarder ".
• Support Video: Enable to support Video Call or not. If it disable, Video call
will be stopped.
• Missed Call: Missed call notify service. Allow you to enter notice receiver
Email address.
• Disable Call Waiting: Disable call waiting feature. When disable call waiting
features, the second incoming call to the user will be rejected by SIPPBX
6200x.
• Disable Conference Call: Disallow to call a conference call.
• Server Transfer: The server will do the transfer instead of CPE. It is
recommended to use it only when CPE doesn’t support call transfer
features. There are 4 options: Transferee Only, Transfer Only, Both or
None.
Security
• Disable Un-Register All: Disable Un-Register all.
• Disable RADIUS Billing Send: Disable RADIUS Billing Send.
• Reject Anonymous Call: Reject the anonymous incoming call or not
Misc
• Sync to Address: Set SIP to header.
• Response to Sending Port: Response to CPE sending port instead of
public contact port.
• Response to Top Via: Response SIP message to the top via IP address and
port.
• Auto Subscriber for MWI: Automatically subscriber MWI service to MWI
server when the user is registered.
• Disable Qop: Disable sending qop tag in SIP Signal 401 and 407
authentication header.
• Auto Subscriber for Presence: Automatically subscriber Presence service
to Presence Server when the user is registered.
• Register Event Log: The system will generate a system event when the
subscriber was registered and unregistered. For a predefined user, the
system will also file a system event when the predefined user is no
responding.
• Secretary: The secretary service. All the calls dial to the supervisor will be
routed to his secretary automatically in order to filter unnecessary call to
supervisor. Enter secretary number once this feature was activated.
Parameter Button
• Copy: Copy service setting from a subscriber.
• Mask: Set the subscriber visual view of the service. If you disable the mask
of a service, the subscriber login won’t be able to see it.
