DES-3326 Layer 3 Fast Ethernet Switch User’s Guide
Figure 6-27. Layer 3 IP Routing Protocol Settings screen
The following fields can then be set:
Parameter Description
DVMRP state
:<Disabled> Allows the Distance-Vector Multicast
Routing Protocol (DVMRP) to be
Enabled or Disabled globally on the
switch.
PIM-DM state:
<Disabled> Allows the Protocol Independent
Multicast − Dense Mode (PIM-DM)
multicast routing protocol to be
Enabled or Disabled globally on the
switch.
Screen Hierarchy
The contents of the Console Interface are arranged following the structure shown in the table below.
The table is arranged starting with the name of the entry on the Main Menu. The sub-menus start with
the name of the first menu, followed by the name of any sub-menus. The sub-menu names are
indented. Some menus are available only when the switch is in IP Routing mode. These menus are
shown in bold typeface.
Main Menu Entry Sub-Menus
Switch Information Switch Information
Remote Management
Setup
Remote Management Setup
Setup Trap Recipients
Switch Settings Switch Settings
Switch Mode Selection
Layer 2 Switch Settings
Layer 3 IP Routing Protocol Settings
Configure Ports Configure Ports
Setup User Accounts Setup User Accounts
110
