Setting the Backfeed Distance
Backfeed distance is the amount the label moves backwards. The backfeed distance
should be equal to or less than the dispense position. If the backfeed distance is greater
than the dispense position then the dispense position automatically changes to match the
backfeed distance.
If you are tearing labels, instead of peeling, the backfeed distance must be 30 dots (0.15
inches) less than the dispense position to account for improper tearing of butt cut
supplies. This causes a 30-dot non-print zone on the supply, but this prevents exposed
adhesive under the printhead.
To access this setting, from the Main Menu, select Setup, Supply, then Positioning.
Follow these steps.
1. Press  until you see Backfeed Dist.
2. Press CHANGE to highlight the backfeed distance options. The current setting is
shown.
3. Press  or  to increment/decrement the backfeed position.
65
CHANGE CANCEL
POSITIONING
Backfeed Dist
[10/200] 65
10 SET CANCEL
←Backfeed Dist →
POSITIONING
Note: Pressing the left function button changes the increment/decrement amount
(changes by 1, 10, or 100).
4.
When you see the backfeed distance you need, press SET to save the change. Press
CANCEL
to leave the backfeed distance unchanged.
5.
Press BACK until you return to the Home/Online screen.
←Backfeed Dist→
65
CHANGE BACK
POSITIONING
