S P E C I F C A T I O N S

P r i n t e r

Height:

11 inches (279mm)

Width:

105 inches (267 mm)

Depth:

16.1 inches (409 mm)

Weight:

22 lb. (10 kg)

Shipping Weight:

25 lb. (11.4 kg)

Power Source:

90-264

with autoselect 50/60Hz

Operating Limits:

Thermal Transfer (ribbon): 40° to 95°F (4° to 35°C)
Thermal Direct: 40° to 104°F (4º to 40°C)
Storage: 15°F to 120°F (-10°C to 49°C)
Humidity: 5% to 90% non-condensing

Printhead:

Thermal at 4.09 inches (103 mm) wide
203 dpi (8.0 dots per mm)

Printing Method:

Thermal Transfer (ribbon) or Thermal Direct

Print Speed:

2.5 ips (64 mm) default for all serial bar codes,
4.0 ips (102 mm) or
6.0 ips (152 mm) default for parallel bar codes

Max Print Area:

4.09 inches x 50.0 inches (102 mm x 1270 mm)

Specifcations A-1
