Altera Stratix V GX FPGA Development Board User Manual
Page 49
Chapter 2: Board Components
2–41
Components and Interfaces
October 2014
Altera Corporation
Stratix V GX FPGA Development Board
Reference Manual
110
HSMB_A12
2.5-V CMOS
D18
Memory address bit
114
HSMB_A13
2.5-V CMOS
A19
Memory address bit
116
HSMB_A14
2.5-V CMOS
B19
Memory address bit
128
HSMB_A15
2.5-V CMOS
C19
Memory address bit
43
HSMB_ADDR_CMD0
2.5-V CMOS
M18
Memory address or command
132
HSMB_BA0
2.5-V CMOS
E18
Memory bank address bit
134
HSMB_BA1
2.5-V CMOS
D19
Memory bank address bit
138
HSMB_BA2
2.5-V CMOS
F18
Memory bank address bit
140
HSMB_BA3
2.5-V CMOS
E19
Memory bank address bit
151
HSMB_C_N
2.5-V CMOS
M15
ODT
149
HSMB_C_P
2.5-V CMOS
N15
QVLD
44
HSMB_CASN
2.5-V CMOS
R16
Memory address or command
150
HSMB_CKE
2.5-V CMOS
G19
Memory address or command
40
HSMB_CLK_IN0
LVDS or 2.5-V
AF29
Primary single-ended clock in
98
HSMB_CLK_IN_N1
LVDS or 2.5-V
T16
LVDS or CMOS clock in 1
152
HSMB_CSN
2.5-V CMOS
H19
Memory address or command
48
HSMB_DM0
2.5-V CMOS
U11
Data mask
72
HSMB_DM1
2.5-V CMOS
J13
Data mask
102
HSMB_DM2
2.5-V CMOS
U12
Data mask
126
HSMB_DM3
2.5-V CMOS
H14
Data mask
47
HSMB_DQ0
2.5-V CMOS
T12
Memory data bus
49
HSMB_DQ1
2.5-V CMOS
R12
Memory data bus
53
HSMB_DQ2
2.5-V CMOS
N12
Memory data bus
55
HSMB_DQ3
2.5-V CMOS
N13
Memory data bus
59
HSMB_DQ4
2.5-V CMOS
M12
Memory data bus
61
HSMB_DQ5
2.5-V CMOS
L12
Memory data bus
65
HSMB_DQ6
2.5-V CMOS
K12
Memory data bus
67
HSMB_DQ7
2.5-V CMOS
J12
Memory data bus
71
HSMB_DQ8
2.5-V CMOS
G12
Memory data bus
73
HSMB_DQ9
2.5-V CMOS
G13
Memory data bus
77
HSMB_DQ10
2.5-V CMOS
F12
Memory data bus
79
HSMB_DQ11
2.5-V CMOS
E12
Memory data bus
83
HSMB_DQ12
2.5-V CMOS
D12
Memory data bus
85
HSMB_DQ13
2.5-V CMOS
C12
Memory data bus
89
HSMB_DQ14
2.5-V CMOS
B13
Memory data bus
91
HSMB_DQ15
2.5-V CMOS
A13
Memory data bus
101
HSMB_DQ16
2.5-V CMOS
U13
Memory data bus
103
HSMB_DQ17
2.5-V CMOS
T13
Memory data bus
Table 2–41. HSMC Port B Pin Assignments, Schematic Signal Names, and Functions (Part 2 of 3)
Board
Reference
(J2)
Schematic Signal Name
I/O Standard
Stratix V GX FPGA
Device Pin Number
Description
