Chapter 2: Board Components 2–27
General User Input/Output
October 2014 Altera Corporation Stratix V GX FPGA Development Board
Reference Manual
Table 2–26 lists the user-defined push button schematic signal names and their
corresponding Stratix V GX FPGA device pin numbers.
Table 2–27 lists the user-defined push button component reference and the
manufacturing information.
User-Defined DIP Switches
Board reference SW1 is an 8-pin DIP switch. The switches are user-defined, and are
for additional FPGA input control. There is no board-specific function for these
switches.
Table 2–28 lists the user-defined DIP switch schematic signal names and their
corresponding Stratix V GX FPGA pin numbers.
Table 2–29 lists the user-defined DIP switch component reference and the
manufacturing information.
Table 2–26. User-Defined Push Button Schematic Signal Names and Functions
Board Reference
Schematic Signal
Name
I/O Standard
Stratix V GX FPGA
Device Pin Number
Description
S5 USER_PB2
2.5-V
(Variable S5_VCCIO_HSMB)
C7
User-Defined push
buttons
S6 USER_PB1 B7
S7 USER_PB0 A7
Table 2–27. User-Defined Push Button Component Reference and Manufacturing Information
Board Reference Description Manufacturer
Manufacturer
Part Number
Manufacturer Website
S5, S6, S7 Push button Dawning Precision Co., Ltd. TS-A02SA-2-S100 www.dawning2.com.tw
Table 2–28. User-Defined DIP Switch Schematic Signal Names and Functions
Board Reference
(SW1)
Schematic
Signal Name
I/O Standard
Stratix V GX FPGA
Device
Pin Number
Description
1 USER_DIPSW0
2.5-V
(Variable S5_VCCIO_HSMB)
E7
User-Defined DIP switch
connected to FPGA
device. When the switch
is in the CLOSED or ON
position, a logic 0 is
selected. When the
switch is in the OPEN or
OFF position, a logic 1 is
selected.
2 USER_DIPSW1 H7
3 USER_DIPSW2 J7
4 USER_DIPSW3 K7
5 USER_DIPSW4 M6
6 USER_DIPSW5 N6
7 USER_DIPSW6 P7
8 USER_DIPSW7 N7
Table 2–29. User-Defined DIP Switch Component Reference and Manufacturing Information
Board Reference Description Manufacturer
Manufacturer
Part Number
Manufacturer Website
SW1 Eight-Position DIP switch C & K Components TDA08H0SB1 www.ck-components.com
