Configuration Settings
Description
Default State/Value
Allow encrypted POF only
If enabled, configuration error will occur if
unencrypted
.pof
is used.
Disable
JTAG Secure
(3)
To disable or enable the JTAG Secure feature.
Disable
Enable Watchdog
To disable or enable the watchdog timer for
remote system upgrade.
Enable
Watchdog value
To set the watchdog timer value for remote system
upgrade.
0x1FFF
(4)
Related Information
•
•
.pof Generation through Convert Programming Files
on page 3-6
Provides more information about setting the ICB during .pof generation using Convert Programming
File.
•
on page 2-24
Provides more information about Instant ON and other power on reset scheme.
•
•
on page 2-16
•
ISP and Real-Time ISP Instructions
•
on page 2-14
Configuration Features
Remote System Upgrade in Dual Compressed Images
MAX 10 devices support the remote system upgrade feature. By default, the remote system upgrade
feature is enabled in all MAX 10 devices when you select the dual compressed image internal
configuration mode.
The remote system upgrade feature in MAX 10 devices offers the following capabilities:
• Manages remote configuration
• Provides error detection, recovery, and information
• Supports direct-to-application configuration image
• Supports compressed and encrypted
.pof
You can use the Altera Dual Configuration IP core or the remote system upgrade circuitry to access the
remote system upgrade block in MAX 10 devices.
(3)
The JTAG Secure feature will be disabled by default in Quartus II. If you are interested in using the JTAG
Secure feature, contact Altera for support.
(4)
The watchdog timer value depends on the MAX 10 you are using. Refer to the Watchdog Timer section for
more information.
2-8
Configuration Features
UG-M10CONFIG
2015.05.04
Altera Corporation
MAX 10 FPGA Configuration Schemes and Features
