7 CONFIGURATION COMMAND Reference

98

Bit 21 is set to 1 for use in Japanese networks; otherwise it must be set to
zero.

All other bits are reserved for future use and must be set to zero.

Note: For ANSI operation bits 8, 9, 10, 11, and 18 must all be set to 1.

7.2.2

MTP Link Set

Syntax:

MTP_LINKSET

Example: MTP_LINKSET 0 321 2 0x0000 456 0x8

Configuration of a link set to an adjacent signaling point.


The logical identity of the link set, in the range 0 to one less than the number

of link sets supported, The linkset_id is used in other commands for

reference.


The signaling point code of the adjacent signaling point.


The number of links to be allocated to the link set.


A 16 bit value reserved for future use to specify run time options. Currently
no options are defined so the parameter must be set to zero.


The signaling point code of the signaling point itself.


The value to be used in the sub-service field of all level 3 messages and

checked for by the discrimination function in all received messages. This is a

4 bit value. Note that for ANSI operation both of the two least significant bits
must be set to 1.

Note: For correct operation the adjacent point code must also appear in a MTP_ROUTE

declaration.

7.2.3

MTP Signaling Link

Syntax:

MTP_LINK

Example: MTP_LINK 0 0 2 2 0 1 0 16 0x0006

Configuration of a signaling link.
