Dialogic

®

DSI SPCI Network Interface Boards Programmer's Manual Issue 5

81

Description:
This message is issued by s7_mgt on completion of the initial configuration

sequence and indicates either success (status=zero) or an error condition

that occurred during configuration. The message is only issued when s7_mgt
is run with the –i command line option specifying the module_id of the
Notification Module to which the message is sent. For example:

s7_mgt

–i0x2d

Note: It is recommended that the user invoke this option and then wait for the

API_MSG_CNF_IND message to ensure the application does not attempt to send

messages until initial configuration is complete.

Parameter Description:

Completion Status
The result of initial configuration coded as follows:

Value

Meaning

0 Success

1

Error opening config.txt file

2

Syntax or value error in config.txt file

3

Error during configuration (invalid parameters)

4

Error during configuration (no response)

6.4.3

Clock Event Indication

Synopsis:
Message issued by the board to indicate on-board clocking related events.

Message Format:

MESSAGE HEADER

Field Name

Meaning

type MVD_MSG_CLK_IND (0x0e23)

id

0

src MVD_TASK_ID

dst

0xdf

rsp_req

0

hclass

0

status Event

ID (see below)

err_info

Reserved for future use

len

0
