7 CONFIGURATION COMMAND Reference
106
7.4.2 TUP Circuit Group Configuration
Syntax: TUP_CFG_CCTGRP
Example: TUP_CFG_CCTGRP 0 3 1 1 0x7fff7fff 0x00000003 0 0x2d
123 0x8 0 0x0
The configuration parameters for a group of TUP circuits.
The group id of the circuit group in the range 0 to one less than the number
of groups supported.
The destination point code for the circuits in the circuit group.
The Circuit Identification Code (CIC) that is allocated to the first circuit in the
circuit group.
The logical id for the first circuit in the circuit group. It must lie in the range 0
to one less than the number of circuits supported.
A 32 bit mask with bits set to indicate which circuits are to be allocated to the
circuit group. Bit zero must always be set as it represents the
base_cic/base_cid. Subsequent bits represent the subsequent circuits.
A 32 bit value containing run-time options for the TUP circuit group (see
"Configure Circuit Group Request" section of the TUP Programmers Manual).
The instance number of the user application. Typically only a single user
application exists so this field would be set to zero.
The module_id of the user application.
Originating Point Code. The local point code for all circuits in the group.
