7.2

MTP Parameters

7.2.1

MTP Global Configuration

Syntax:

MTP_CONFIG

Example: MTP_CONFIG 0 0 0x00040f00

The global configuration parameters for the Message Transfer Part (MTP).

,
These parameters are reserved for backwards compatibility. For applications

conforming to this release of the documentation these parameters must
always be set to zero.


A 32 bit value containing run-time options for the operation of the MTP as
follows:

Bit 0 is set to 1 to disable the MTP3 message discrimination function
(allowing the signaling point to receive all messages irrespective of the

destination point code contained in the message) or zero to allow the
discrimination function to function normally.

Bit 1 is set to 1 to disable sub-service field (SSF) discrimination. If this bit is

set to zero, received MSUs whose ssf value does not match the configured ssf

value for that link set are discarded.

Bit 2 is set to 1 to cause MTP3 to generate a UPU (User Part Unavailable)

message to the network on receipt of a message containing a Service

Indicator value that has not been configured. If set to zero the message is

discarded without sending UPU.

Bit 8 is set to 1 to select ANSI operation; otherwise it must be set to zero.

Bits 9 and 20 are used to select the point codes used in the MTP routing

lable as defined below:

Bit 9

Bit 20

Point Code

Description

0 0

14-bit

ITU

0 1

16-bit

Japan

1 x

(1)

24-bit ANSI

(1)

x indicates don’t care.

Bit 10 is set to 1 for ANSI operation; otherwise it is set to zero.

Bit 11 is set to 1 for ANSI operation; otherwise it is set to zero.

Bit 18 is used to control MTP functionality in the event of detection of RPO

(Remote Processor Outage). If set to 1, RPO is handled in accordance with

the ITU-T 1992 (and later) recommendations. If set to zero, on detection of
RPO the signaling link is taken out of service and restoration commenced.

This bit is usually set to 1.

Bit 20 used in conjunction with bit 9 to select point codes (see above).
