Dialogic ® DSI SPCI Network Interface Boards Programmer's Manual Issue 5
105
7.4 TUP Parameters
7.4.1 Global TUP Configuration
Syntax: TUP_CONFIG
Example: TUP_CONFIG 0 0 0x2d 0x8541 4 128
The global configuration parameters for the TUP module.
,
Reserved for backwards compatibility. These fields should be set to zero.
The module_id of the application running on the host that uses the TUP
module.
A 16 bit value containing global run-time options for the operation of the TUP
module. The meaning of each bit is as defined for the 'options' parameter in
the TUP Configure Request message as detailed in the TUP Programmer's
Manual.
The maximum number of TUP circuit groups that the user intends to use. This
must not exceed the maximum number of circuit groups supported otherwise
module configuration will fail. Typically would be set to the
maximum number of circuit groups supported.
The maximum number of TUP circuits that the user intends to use. This must
not exceed the maximum number of circuits supported otherwise module
configuration will fail. Typically is set to 32 times the number of
groups for E1 operation and 24 times the number of circuit groups for T1
operation.
Note: The valid range for the circuit identifier (cid) is from zero up to one less than the
maximum number of circuits (num_ccts).
Optional parameter for use when operating in dual resilient configuration.
This parameter is the module_id of the "partner" TUP module (equivalent to
the "ucic_id" field in the TUP Configure Request message as documented in
the TUP Programmer’s Manual).
