6 Message Reference

68

timeslot
The timeslot number on the T1/E1 line interface unit on which the fixed data

is transmitted. The valid range for timeslot is 1 to 31 for an E1 interface and

1 to 24 for a T1 interface.

pattern
The value of the fixed data to be generated. The value must be in the range 0

to 255. Typical values are 0xff for an "all ones" idle pattern, or 0x2a for an

ITU-T E1 idle pattern.

Status Response
The confirmation message (if requested) indicates success by status of zero.

On error, the following status values can be found in the confirmation
message.

Value

Mnemonic

Description

0xd2

MVIP_INVALID_STREAM

Invalid stream specified in listen request.

0xd3

MVIP_INVALID_TIMESLOT

Invalid timeslot specified in listen request.

0xff

None

Fixed pattern generation request failed.

6.3.9

Reset Switch Request

Synopsis:
Resets the digital switch to its default state in accordance with the current

board configuration.

Message Format:

MESSAGE HEADER

Field Name

Meaning

type MVD_MSG_RESETSWX (0x7e00)

id

0

src

Sending Module ID

dst MVD_TASK_ID (0x10)

rsp_req

used to request a confirmation

hclass

0

status

0

err_info

0

len

0
