Dialogic ® DSI SPCI Network Interface Boards Programmer's Manual Issue 5
91
7 CONFIGURATION COMMAND Reference
This chapter describes the commands and parameters used in the protocol
configuration file config.txt. These are used by the s7_mgt utility to perform
single-shot configuration of the protocol stack at startup.
7.1 Physical Interface Parameters
7.1.1 SS7_BOARD Command
Syntax: SS7_BOARD
Example: SS7_BOARD 0 SPCI4 0x0043 ss7.dc3 ISUP-L
Command to configure an SPCI4 board in the system.
The logical id of the board within the system in the range 0 ... 15.
The board type within the system. Possible values are:
• SPCI2S for Dialogic ® DSI SPCI2S Network Interface Boards.
• SPCI4 for Dialogic ® DSI SPCI4 Network Interface Boards boards.
A 16 bit value that provides additional level 1 configuration for the board. The
meaning of each bit may vary with different board types. The bits in the flags
field are used as follows:
Bit 0 controls the reference source used for on-board clocks when acting as
CT bus Primary Master. If set to 1 then the clock is recovered from one of the
line interfaces. If set to zero then the on-board clock oscillator is used.
Bit 1 is reserved for future use and must always be set to 1.
Bit 6 and 7 together select the initial clocking mode for the CT bus as shown
in the following table. The clocking mode can subsequently modified
dynamically using the MVD_MSG_CNFCLOCK message:
