6 Message Reference

42

Run Mode
Value

Run Mode
Mnemonic

Protocols selected to run on the board

1

DTI

Digital Trunk Interface only, no protocol software. This
mode does NOT require the use of a software license
button.

2

MTP2

MTP2 protocol only.

3

MTP

MTP3 plus MTP2 protocols.

25

ISUP-S

ISUP, small version, plus all MTP.

4

ISUP

ISUP, regular version, plus all MTP.

5

ISUP-L

ISUP, large version, plus all MTP.

26

TUP-S

TUP, small version, plus all MTP.

6

TUP

TUP, regular version, plus all MTP.

7

TUP-L

TUP, large version, plus all MTP.

See section 2.3.2

Capacity

for details of the capacity for modules running on

the DSI SPCI Boards.

Status Response
The confirmation message (if requested) indicates success by status of zero.

No status values indicating errors are defined.

6.2.3

Board Status Indication

Synopsis
Message sent to the application on completion of the reset and download

sequence or on detection of a board status event.

Format

MESSAGE HEADER

Field Name

Meaning

type

SSD_MSG_STATE_IND (0x06a0)

id

board_id

src

SSD_TASK_ID (0x20)

dst

mgmt_id for SSD

rsp_req

0

hclass

0

status Event

Type (see below)

err_info

0

len

0
