Dialogic ® DSI SPCI Network Interface Boards Programmer's Manual Issue 5
59
6.3.3 LIU Read Configuration Request
Synopsis:
Message sent by the application to read back the current LIU configuration
from the DSI SPCI Board.
Message Format:
MESSAGE HEADER
Field Name Meaning
type LIU_MSG_R_CONFIG (0x5e37)
id liu_id
src Sending Module ID
dst MVD_TASK_ID (0x10)
rsp_req used to request a confirmation
hclass 0
status Status Response (if confirmation requested)
err_info 0
len 40
PARAMETER AREA
Offset Size Name
0 40 Parameter area formatted as for the LIU_MSG_CONFIG
message. The user should set the fields to zero and the
module writes the current configuration parameters in the
confirmation message.
Description:
This message is sent to the DSI SPCI Board to read back the current
operating configuration of the Line Interface Unit.
The user should always request a confirmation message. This indicates
success by status of zero, and contains the current configuration parameters
in the parameter area of the message.
Status Response
The confirmation message (if requested) indicates success by status of zero.
On error, the following status value can be found in the confirmation
message.
