6 Message Reference
40
num_boards
The maximum number of boards that ssd is required to manage. This must
not exceed 16.
Status Response
The confirmation message (if requested) indicates success by status of zero.
On error, the following value can be found in the status message
confirmation.
Value Mnemonic Description
2 SSD_BAD_PARAM The SSD Reset Request message was incorrectly formatted.
6.2.2 Board Reset Request
Synopsis:
Message sent to SSD to cause a single board to be reset and a code file
downloaded.
Note: When using s7_mgt, this message is generated by s7_mgt and must not be
generated by the user.
Message Format:
MESSAGE HEADER
Field Name Meaning
type SSD_MSG_RST_BOARD (0x7681)
id board_id
src Sending module's module_id
dst SSD_TASK_ID (0x20)
rsp_req used to request a confirmation
hclass 0
status Status Response (if confirmation requested)
err_info 0
len 26
PARAMETER AREA
Offset Size Name
0 2 board_type
2 4 phy_id
6 18 code_file
24 2 run_mode
