Dialogic

®

DSI SPCI Network Interface Boards Programmer's Manual Issue 5

37

6.1.3

MTP Interface Messages

MTP Interface Messages allow signaling links to be activated and deactivated
by the user and provide a mechanism for communication between the MTP3
module and the user part module (e.g., ISUP or TUP). In many cases, the

user part module is an SS7 Protocol binary so the user does not need to

handle the MTP-TRANSFER, MTP-PAUSE, MTP_RESUME & MTP-STATUS
primitives as they pass directly between MTP3 and the user part module.

In the case that the user application is implementing the user part

functionality, then the MTP primitives are applicable and these are

documented in the MTP Interface messages section.

6.1.4

Event Indication Messages

Event Indication Messages are the mechanism by which protocol and software
error events are reported to the application. These messages are generated

asynchronously by different modules within the stack.

6.1.5

Message Summary Table

The following table lists, by message type, all the messages described in this
manual:

Table 10: Message Summary

Message
Type

Mnemonic

Description

0x0008

MGT_MSG_EVENT_IND Error

Indication

0x0201

MGT_MSG_SS7_STATE

MTP2 Level 2 State Indication

0x0202

MGT_MSG_SS7_EVENT MTP2

Q.752

Event

Indication

0x0301

MGT_MSG_MTP_EVENT MTP3

Q.752

Event

Indication

0x06a0

SSD_MSG_STATE_IND

Board Status Indication

0x0e01

MVD_MSG_LIU_STATUS

LIU Status Indication

0x0e23

MVD_MSG_CLK_IND Clock

Event

Indication

0x0f09

API_MSG_CNF_IND

s7_mgt Completion Status Indication

0x1e37

Confirmation of LIU_MSG_R_CONFIG

0x1e38

Confirmation of LIU_MSG_R_CONTROL

0x1e39

Confirmation of LIU_MSG_R_STATE

0x3312

Confirmation of MTP_MSG_CNF_ROUTE

0x3680

Confirmation of SSD_MSG_RESET

0x3681

Confirmation of SSD_MSG_RST_BOARD

0x3e00

Confirmation of MVD_MSG_RESETSWX

0x3e15

Confirmation of MVD_MSG_SC_FIXDATA

0x3e17

Confirmation of MVD_MSG_SC_LISTEN
