Dialogic

®

DSI SPCI Network Interface Boards Programmer's Manual Issue 5

51

Format

MESSAGE HEADER

Field Name

Meaning

type

MGT_MSG_R_BRDINFO (0x6f0d)

id

0

src

Sending module_id

dst

MGMT_TASK_ID (0x8e)

rsp_req

used to request a confirmation

hclass

0

status

Status Response (if confirmation requested)

err_info

0

len

60

PARAMETER AREA

Offset Size

Name

0 1 board_type

1 1 board_rev

2 1 reserved

3 1 swa

4 1 swb

5 1 reserved

6 1 reserved

7 1 reserved

8 1 prom_maj_rev

9 1 prom_min_rev

10 8

esn

18 8

lsn

26 4

reserved

30 20 reserved

50 10 reserved

Parameter Description:

board_type
The DSI SPCI Board type. The table shows the possible values and their
meaning.

Value

Mnemonic

Meaning

2

BRDINFO_BTYPE_SPCI

SPCI2S or SPCI4 board
