6 Message Reference

58

ais_gen

Description

0

Do not change AIS / Blue alarm generation mode.

1

Disabled - do not generate AIS / Blue alarm.

2

Enabled - generate AIS / Blue alarm.

rai_gen
The mode used to generate the Remote Alarm Indication (Yellow Alarm)
taken from the following table:

rai_gen

Description

0

Do not change RAI / Yellow alarm generation mode.

1

Disabled - do not generate RAI / Yellow alarm.

2

Forced active - generate RAI / Yellow alarm.

3

Automatic generation of RAI / Yellow alarm upon loss of
synchronization.

loop_mode
The diagnostic loop back mode taken from the following table:

loop_mode

Description

0

Do not change diagnostic loop back mode.

1

Disabled - remove any diagnostic loop.

2 Payload

loopback.

3 Remote

loopback.

4 Local

loopback.

Status Response
The confirmation message (if requested) indicates success by status of zero.

On error, the following status values can be found in the confirmation

message.

Value

Mnemonic

Description

0x01 None

Invalid

framer

ID.

0x02 None

Invalid

message

length.

0x03

None

Control parameters are not consistent with the type of device being
controlled or with each other.
