7 CONFIGURATION COMMAND Reference

104


A 32 bit mask with bits set to indicate which circuits are to be allocated to the

circuit group. Bit zero must always be set as it represents the

base_cic/base_cid. Subsequent bits represent the subsequent circuits. Note

that ANSI circuit groups are not permitted to contain more than 24 circuits.


A 32 bit value containing run-time options for the ISUP circuit group (see

"Configure Circuit Group Request" section of the ISUP Programmer’s Manual).
Bits 0 through 15 are equivalent to the "options" field and bits 16 through 31
represent the "ext_options" field as detailed in the ISUP Programmer’s

Manual.


The instance number of the user application. Typically only a single user

application exists so this field would be set to zero.


The module_id of the user application.


Originating Point Code. The local point code for all circuits in the group.


The value to be used in the sub-service field of all ISUP messages for this

circuit group.


The protocol "variant" for this circuit group. Refer to the ISUP Programmer’s

Manual for full details.


A 32 bit value containing additional run-time options for the ISUP circuit

group (see "Configure Circuit Group Request" section of the ISUP

Programmer’s Manual). Bits 0 through 31 are equivalent to the
"ext_1_options" as detailed in the ISUP Programmer’s Manual.
