Dialogic ® DSI SPCI Network Interface Boards Programmer's Manual Issue 5
43
Description
Event Type
This message is used to convey the status of a board reset operation (success
of failure) to the user. The status is indicated in the status field of the
message header. The following table shows the possible Event Type values:
Value Meaning
0x60 Reset successful
0x62 Board failure
0x66 License validation failure
0x67 License appears corrupt
6.2.4 Board Configuration Request
Synopsis:
Message sent to a board immediately after starting the code running to
provide protocol configuration parameters.
Note: When using s7_mgt, this message is generated by s7_mgt and must not be
generated by the user.
Message Format:
MESSAGE HEADER
Field Name Meaning
type MGT_MSG_CONFIG0 (0x7F10)
id 0
src Sending module's module_id
dst MGMT_TASK_ID (0x8e)
rsp_req used to request a confirmation
hclass 0
status Status Response (if confirmation requested)
err_info 0
len 68
PARAMETER AREA
Offset Size Name
0 2 config_type (Must be set to 2)
2 2 flags
4 2 l1_flags
6 2 l2_flags
