Dialogic

®

DSI SPCI Network Interface Boards Programmer's Manual Issue 5

49

6.2.5

General Module Identification Message

Synopsis:
Message used to request the module type and software revision number.

Message Format:

MESSAGE HEADER

Field Name

Meaning

Type

GEN_MSG_MOD_IDENT (0x6111)

Id

0

Src

Sending module_id

Dst

on-board management task (0x8e)

rsp_req

used to request a confirmation

hclass

0

status

Status Response – zero on success

err_info

0

len

28

PARAMETER AREA

Offset Size

Name

0 2 reserved

2 1 maj_rev

3 1 min_rev

4 24 text

Description:
This message is provided to request a reply indicating the software version
for module under test. On receipt of this request, the module returns the

message with status "SUCCESS" to the sender including the information

requested.

Note: This message can be sent to the on-board management task to obtain the version

of the code file running on a live system.

Parameter Description:

maj_rev
Major revision identifier for the object being queried.

min_rev
Minor revision identifier for the object being queried.
