6 Message Reference

38

0x3e18

Confirmation of MVD_MSG_SC_DRIVE_LIU

0x3e1f

Confirmation of MVD_MSG_SC_CONNECT

0x3e20

Confirmation of MVD_MSG_CNFCLOCK

0x3e21

Confirmation of MVD_MSG_CLK_PRI

0x3e34

Confirmation of LIU_MSG_CONFIG

0x3e35

Confirmation of LIU_MSG_CONTROL

0x3f10

Confirmation of MGT_MSG_CONFIG0

0x5e37

LIU_MSG_R_CONFIG

LIU Read Configuration Request

0x5e38

LIU_MSG_R_CONTROL

LIU Read Configuration Request

0x5e39

LIU_MSG_R_STATE

LIU State Request

0x6111

GEN_MSG_MOD_IDENT

General Module Identification Message

0x6f0d

MGT_MSG_R_BRDINFO

Read Board Info Request Message

0x7680

SSD_MSG_RESET SSD

Reset

Request

0x7681

SSD_MSG_RST_BOARD Board

Reset

Request

0x7e00

MVD_MSG_RESETSWX Reset

Switch

Request

0x7e15

MVD_MSG_SC_FIXDATA

Fixed Data Request

0x7e17

MVD_MSG_SC_LISTEN SCbus

Listen

Request

0x7e18

MVD_MSG_SC_DRIVE_LIU

SCbus Initialization Request

0x7e1f

MVD_MSG_SC_CONNECT SCbus

Connect

Request

0x7e20

MVD_MSG_CNFCLOCK

Configure Clock Request

0x7e21

MVD_MSG_CLK_PRI

Configure Clock Priority Request

0x7e34

LIU_MSG_CONFIG

LIU Configuration Request

0x7e35

LIU_MSG_CONTROL LIU

Control

Request

0x7f10

MGT_MSG_CONFIG0 Board

Configuration

Request

0x830a

Confirmation of MTP_MSG_ACT_SL

0x830b

Confirmation of MTP_MSG_DEACT_SL
