P
an/EQ/Send-return eff
ect
38
Track parameters
Parameters available to each track
Monaural tracks: 1 ~16
Stereo tracks: 1/2 ~ 15/16
*Switch parameters with asterisks (*) On/Off using the ENTER key.
Display Parameter
Setting range:
Initial value
Explanation
Monaural
tracks
Stereo
tracks
Master
track
PAN PAN
L100~
R100
Adjusts a track’s PAN. In case of a stereo track
adjusts the volume balance between the left and
right tracks.
EQ HI EQ boost for high pitch/frequency range
EQ HI G EQ HI GAIN*
−12~
+12dB
:0dB
Adjust amount of boost/cut of high frequencies by
-12 ~ +12 dB. This parameter is shown only when
EQ HI is on.
EQ HI F
EQ HI
FREQUENCY*
500(Hz)~
18(kHz)
:8.0(kHz)
Adjust EQ boost/cut frequency of high frequencies.
This parameter is shown only when EQ HI is on.
EQ MID EQ boost for middle pitch/frequency range
EQ MID G EQ MID GAIN*
−12~
+12dB
:0dB
Adjust amount of boost/cut of medium frequencies
by -12 ~ +12 dB. This parameter is shown only
when EQ MID is on.
EQ MID F
EQ MID
FREQUENCY*
40(Hz)~
18(kHz)
:1..0(kHz)
Adjust EQ boost/cut frequency of medium
frequencies. This parameter is shown only when
EQ MID is on.
EQ MID Q
EQ MID
Q-FACTOR*
0.1~1.0
:0.5
Adjust the Q value (width of the frequency band
affected) of medium frequencies. This parameter is
shown only when EQ MID is on.
EQ LOW EQ boost for low pitch/frequency range
EQ LO G EQ LOW GAIN*
−12~
+12dB
:0dB
Adjust amount of boost/cut of low frequencies by
-12 ~+12dB. This parameter is shown only when
EQ LO is on.
EQ LO F
EQ LOW
FREQUENCY*
40(Hz)~
1.6(kHz)
:125(Hz)
Adjust EQ boost/cut frequency of low frequencies .
This parameter is shown only when EQ LO is on.
SEND-RETURN EFFECT levels
REVERB
SEND
REVERB
SEND LEVEL*
0~100
:0
Adjust the signal level sent from tracks to the
Reverb effect.
CHORUS
SEND
CHORUS/
DELAY SEND
LEVEL*
0~100
:0
Adjust the signal level sent from tracks to the
Chorus/Delay effect.
FADER FADER
0~127
:0
Adjust the sound volume.
ST LINK STEREO LINK
On/Off
:Off
Switch on/off to set the stereo link function that
connects 2 monaural tracks together. (→P.20)
INVERT INVERT
On/Off
:Off
Set whether the phase of a track is inverted or not.
Off: normal phase, ON: inverted phase.
Mixing
