CenterLine 2.02
98-05054 R6
5
CHAPTER 2 - SETUP
It is assumed that the CenterLine system has been properly installed. Refer to the following Center-
Line diagrams for system configuration.
QUICK START GUIDE
First Time Start-Up Sequence
1. Turn ON power to CenterLine.
2. The lightbar will perform a start-up sequence.
3. The lightbar will display the current software version.
4. The lightbar will display .
5. Using the Arrow buttons, scroll until is displayed on the lightbar. Press the
Enter button.
6. Configure the CenterLine system by choosing the appropriate settings under ANCE>, , and . It is important to enter the correct swath width for
operation.
7. Use the Arrow buttons to locate . Press the Enter button. The operator will
return to the main menu.
8. Once is displayed on the lightbar, press ENTER to begin operation.
Typical Start-Up Sequence
1. Turn ON power to CenterLine.
2. The lightbar will perform a start-up sequence.
3. The lightbar will display the current software version.
4. The lightbar will display .
5. will remain visible on the lightbar until the Enter button is pressed to begin oper-
ation or the Arrow buttons are pressed to select a menu option.
Arrow buttons
Enter button
