24 Chapter 2 - Setup
Receiver
The Receiver diagnostic test displays the attached GPS receiver’s current configuration and status.
The information is displayed in the text window of the lightbar. To begin the receiver check, navigate
to and press the Enter button. Use the Arrow buttons to select and press
the Enter button. The lightbar will display the diagnostic message.
Table 2-16: Receiver Messages
Lightbar
The Lightbar diagnostic test initiates an illumination sequence of all the LEDs in the test window, fol-
lowed by a brightness control sequence. This will allow the verification that all LEDs on the Center-
Line lightbar are working correctly. To begin the lightbar check, navigate to and press the
Enter button. Use the Arrow buttons to select and press the Enter button. The illumi-
nation sequence will begin. Once the test has concluded, the lightbar will display .
Level
Once the antenna height has been entered (refer to CHAPTER 2 - ANTENNA - HEIGHT) and the
vehicle is situated on a level surface, the Tilt Compensation Module should be calibrated (leveled).
To access the level feature, navigate to and press the Enter button. Use the Arrow but-
tons to select and press the Enter button. Highlight the Level menu item using the
Arrow buttons and press the Enter button. The lightbar will display during calibration fol-
lowed by once the calibration is complete.
e-Dif
The accuracy of the position information provided by the e-Dif GPS receiver slowly deteriorates with
time since the last calibration. Due to this factor, it is recommended that the e-Dif receiver be re-cal-
ibrated approximately every 1 to 2 hours to maintain accuracy for position information. The e-Dif tool
allows the operator to re-calibrate the e-Dif receiver by halting the vehicle and selecting e-Dif in the
menu.
Message Description
GPS Status If the lightbar is not receiving GPS data, the text window message will be displayed as
. If the lightbar is receiving GPS data but the data is not differentially cor-
rected, the text window message will be displayed as .
DGPS Status If the lightbar is receiving GPS data that is differentially corrected, the text window will
display the message .
NMEA Strings Returns the name of each NMEA string currently being received from the receiver. For
example, if the NMEA GPGGA string is being received from the receiver, the text win-
dow will display .
Data Rate Returns the current receiver data rate. This is typically 5 Hz. The rate is displayed in
the text window (e.g., <5 HZ>).
Arrow buttons
Enter button
