8 Chapter 2 - Setup
Figure 2-4: Guidance Setup Flow
Table 2-1: Guidance Default Settings
Swath Manager 5
The Guidance parameter is only displayed when Swath Manager 5 is connected to
the system. If Swath Manager 5 is not being used, this section is not required and can be skipped.
To adjust settings in mode, use the Arrow keys until
is displayed and press the Enter button. The Swath Manager menu contains four parameters:
• % overlap
• Sections
• Width 1-5
• Delay
Setting Default Value Change at Initial Startup
Width 30.0 feet/10 meters Required
Ahead 1.5 seconds Optional
Antenna - Direction None Recommended
Antenna - Distance 0.0 feet Recommended
Antenna - Height 9.8 feet / 2.9 meters Recommended
Status Detect Off Optional
Alarm Off Recommended
GPS Type DGPS Recommended
1 Hz MSG Yes Not Recommended
Guidance
Width
Ahead
Antenna
Status
Alarm
GPS Type
1 Hz MSG
Next
To Start
