CENTERLINE SETUP
CenterLine Setup allows for the configuration of the CenterLine product to best suit current guidance
and mapping needs. For a complete overview of the setup process, refer to Figure 2-31 (page 22).
CenterLine Setup consists of three sub-menus:
• Guidance
• Lightbar
• System
The top level of CenterLine software contains three menus available for selection: ,
, and . To access the setup menus, use the Arrow buttons to scroll to
and press the Enter button. Once in mode, menu options will consist of ,
, and . Access to setup options is achieved by pressing the Enter button.
Figure 2-3: CenterLine Setup Flow
Guidance Mode
Guidance Mode allows for the establishment of several parameters that pertain to guidance func-
tionality. To access Guidance Mode, use the Arrow buttons to scroll through the menu selections
until appears on the lightbar. Press the Enter button.
If the first menu item displayed is , Swath Manager 5 has been detected on the sys-
tem and needs to be configured. Refer to CHAPTER 2 - SWATH MANAGER for additional informa-
tion.
Setup
Tools
Guidance
Lightbar
System
Start
Arrow buttons
Enter button
