16 Chapter 2 - Setup
Table 2-8: Lightbar Menu Settings
Spacing
The Spacing setting allows the selection of the distance that a single light on the lightbar LED repre-
sents. To change the spacing setting, navigate to , use the Arrow buttons until ING> is displayed and press the Enter button. Use the Up Arrow button to increase distance; use the
Down Arrow button to decrease distance. Press the Enter button once the appropriate distance is
displayed to save the settings and return to the Lightbar setup menu. The spacing range is 0.5 feet
to 9.5 feet in 0.1 foot increments.
Figure 2-23: Establishing Spacing Distance
Mode
The Mode setting defines how the row of LEDs are interpreted. The center stack of LEDs can repre-
sent either the current guideline or the vehicle. To change the Mode setting, navigate to BAR>, use the Arrow buttons until is displayed and press the Enter button. Options
include and . Use the Arrow buttons to select the appropriate option and
press the Enter button to save the setting and return to the Lightbar setup menu.
Figure 2-24: Establishing Mode
Setting Default Value Change at Startup
Spacing 1.5 feet Optional
Mode Swath Optional
Text 1 X-Track Error Optional
Text 2 Applied Area Optional
Steer Bar No Optional
1.5 Spacing
Vehicle Mode
Swath
Arrow buttons
Enter button
