CenterLine 2.02
98-05054 R6
25
To re-calibrate the e-Dif receiver, navigate to and press the Enter button. Use the
Arrow keys to select and press the Enter button. The lightbar will display until the
receiver is re-calibrated, followed by once the process is complete.
e-Dif Info
The e-Dif Info function appears only when the CenterLine system detects that an e-Dif GPS receiver
is present and calibrated. This receiver diagnostic test queries that attached e-Dif GPS receiver and
displays the generated position information. The information is displayed on the lightbar. To start the
e-Dif diagnostic test, navigate to and press the Enter button. Use the Arrow buttons to
select and press the Enter button. The lightbar will display a diagnostic message as
illustrated in Table 2-17.
Table 2-17: e-Dif Diagnostic Messages
Demo
The Demo mode displays simulated guidance information on the lightbar. This is used primarily by
sales personnel to demonstrate the capabilities of the CenterLine system. To access Demo mode,
navigate to and press the Enter button. Use the Arrow buttons to select and
press the Enter button.
Next
The Next selection saves the setup information and returns the operator to the starting point on the
CenterLine menu.
To Start
The To Start selection saves the setup information and returns the operator to the starting point on
the CenterLine menu.
Message Description
Number of Satellites Displays the number of satellites that are providing a reliable signal to the GPS
receiver.
E Correction Age Displays the time since the last re-calibration.
Current Last Position Displays the latitude, longitude, and height of the last re-calibration position.
Enter button
Arrow buttons
