18 Chapter 2 - Setup
Table 2-10: Text 1 Settings
Text 2
To select the Text 2 setting, navigate to , use the Arrow buttons until is dis-
played and press the Enter button. Scroll through the available options using the Arrow buttons until
the desired message is located. Press the Enter button to save the setting and advance to the
menu item.
Figure 2-26: Selecting Text 2 Message
Table 2-11: Text 2 Settings
Message Description
X-Track Displays the error (in distance) between the current guideline and the vehicle position.
Swath # Displays the current guideline number.
Ground Speed Displays the vehicle ground speed.
Area Applied Displays the amount of area covered, sprayed, or spread in acres or hectares.
COG Course on Ground, displays the vehicle heading in degrees.
Off When OFF is selected, no message is displayed in the message slot.
Message Description
X-Track Displays the error (in distance) between the current guideline and the vehicle position.
Swath # Displays the current guideline number.
Ground Speed Displays the vehicle ground speed.
Area Applied Displays the amount of area covered, sprayed, or spread in acres or hectares.
COG Course on Ground, displays the vehicle heading in degrees.
Off When OFF is selected, no message is displayed in the message slot.
X-Track Text 2
Swath#
Speed
Area
Course
Off
Arrow buttons
Enter button
