TeeJet CenterLine User Guide v2.02 - Manual (Page 21)

CenterLine 2.02
98-05054 R6
17
Table 2-9: Mode Settings
Text 1 and Text 2
Text 1 and Text 2 settings allow the operator to select text messages from pre-determined guidance
information messages. The messages are displayed on the lightbar text window for 15 seconds
when first enabled and used during guidance operation. A maximum of two text messages can be
displayed.
Text 1
To select the Text1 setting, navigate to , use the Arrow buttons until is dis-
played and press the Enter button. Scroll through the available options using the Arrow buttons until
the desired message is located. Press the Enter button to save the setting and advance to the
menu item.
Figure 2-25: Selecting Text 1 Message
Setting Description
Swath The center stack of LEDs represent the current guideline. Steer the vehicle to bring the moving
LED back to center.
Vehicle The center stack of LEDs represent the vehicle’s position. Steer the vehicle to bring the center
lights toward the moving LED.
X-Track Text 1
Swath#
Speed
Area
Course
Off
Arrow buttons
Enter button
